P903M0

Cable Parameter:
Model:P903
Conductor: OCC Copper
Wire diameter: 2.5Sq (52core x0.25mm)
Structure: 3P cabtire
Insulator（inner）: PE
Outer Sheath: Polyurethane
4-layer Shield:
1st：100%Transparent Membrane
2nd：80% Pure Copper Braid
3nd:100% Aluminum Foil
4nd:Conductive PVC
O.D. :13.6mm
Rated V/A: 600V / 30A

Connector Plug Parameter:
Model: M100
Conductor:99.998% Pure Copper
Body:Nylon/Fiberglass  (Bayer-2805)
Dimensions: 52.6mm H X 38.5mmφ Overall Length：73.5mm
Connections: Hex Screws
Suitable Wire: Max.4.5mm(11 to 14 AWG)
Rating: 15A 250V A.C.
Install The Cable Diameter: 6mm-18mm

Model: F100
Conductor: 99.998% Pure Copper
Body:Nylon/Fiberglass(Bayer-2805)
Dimensions: 49mm H X 38.5mmφ Overall Length：72m
Connections:Set Screws
Suitable Wire: Max.6mm (10 to 14 AWG)
Rating: 15A/125V 10A/250V
Install The Cable Diameter: 6mm-18mm
